MILL-MAX MFG CORP
#110-91-328-41-001000
Solder Tab Socket Contact Beryllium Copper
SKU
#
40308695018
Manufacturer Series:
110
Specifications
Type:
Socket Contact
Contact Termination:
Solder Tab
Wire Insulation Dia.:
0.38-0.63mm (0.015-0.025")
Contact Diameter:
0.50 mm (0.020")
Length:
35.56mm (1.4 in.)
Rating - Current:
3A
Material:
Beryllium Copper
Finish-Plating:
Gold Over Nickel
Packaging:
Tube
Description
Pin and Socket Contacts: Type - Socket Contact; Contact Termination - Solder Tab; Wire Insulation Dia. - 0.38-0.63mm (0.015-0.025"); Contact Diameter - 0.50 mm (0.020"); Length - 35.56mm (1.400"); Rating - Current - 3A; Material - Beryllium Copper; Finish-Plating - Gold Over Nickel; Packaging - Tube; Additional Information - Operating Temperature: -55 to 125 deg C (-67 to 257 deg F); Manufacturer Series - 110
Additional Info: Operating Temperature: -55 to 125 deg C (-67 to 257 deg F)
