Angled Female Connector, 2P, 14A, 320/630V, 28-12 AWG, 2 Contacts, -60 to 85 deg C

Description

Modular System - Inserts: Type - Female Connector; Contact Connection Type - Cage-Clamp; Positions - 2P; Rating - Current - 14A; Rating - Voltage - 320/630V; Wire Range - 28-12 AWG; Number of Contacts - 2; Temperature Rating - -60 to 85 deg C (-76 to 185 deg F); Material Rating - UL 94 V-0; Additional Information - Pin Spacing: 5.08 mm, Color: Orange, Insulating Material: Polyamide 66, Contact: Tin-Plated Copper Alloy, Dimensions: 23.90 mm H x 12.56 mm W x 22.75 mm D

Additional Info: Pin Spacing: 5.08 mm, Color: Orange, Insulating Material: Polyamide 66, Contact: Tin-Plated Copper Alloy, Dimensions: 23.90 mm H x 12.56 mm W x 22.75 mm D
