3M
#31049
Scotchlok™ Lug, Compression; Copper; 1/2 in.; 1 Hole; 250 MCM; Yellow
SKU
#
05400712618
Manufacturer Series:
31000
Specifications
Country of Origin:
Chile - Subject to change
Type:
Compression Terminal
Material:
Copper
Voltage:
35kV
Barrel Length/Type:
Long
Lug L x Tongue W:
3.38 x 1.11 in.
Stud Holes:
1
Conductor Type:
Copper
Conductor Size - Code:
250 MCM
Screw/Stud Size:
1/2 in.
Color Code:
Yellow
Description
Cable Lugs: Type - Compression Terminal; Material - Copper; Voltage - 35 kV; Barrel Length/Type - Long; Lug L x Tongue W - 3.38 x 1.11 in.; Stud Holes - 1H; Conductor Type - CU; Conductor Size - Code - 250 MCM; Screw/Stud Size - 1/2 in.; Color Code - Yellow; Additional Information - Barrel Length: 1.50 in.; Manufacturer Series - Scotchlok 31000
Additional Info: Barrel Length: 1.50 in.
