APEX TOOL GROUP
#PL350
Tip; Soldering Iron; Chisel Shape; 0.379 in. Inner Diameter x 0.400 in. Outer Diameter Tip; 1.120 in. Reach; Iron, Nickel, Chromium Plated Solid Copper
SKU
#
03710303703
Manufacturer Series:
PL series
Specifications
Type:
Soldering Iron Tip
Shape-Style:
Chisel
Tip Size:
0.379 in. (9.65 mm) ID x 0.400 in. (10.14 mm) OD
Reach:
1.120 in. (28.45 mm)
Material Type:
Solid Copper
Material Finish:
Iron, Nickel, Chromium
Use With:
360, 362, 37UG, 537S, 1237S, 4037S Thread-On Tip Heaters, 535S, 1235S, 4035S Thread-In Tip Heaters
Description
Tip; Soldering; Large Chisel Shape; 0.400 in. Tip; Iron, Nickel, Chromium Plated Solid Copper; 1.12 in. Reach; Used with 360, 362, 37UG, 537S, 1237S and 4037S
- Thread on and thread in precision tips for standard and DI line heaters
- Designed to provide maximum heat transfer from the heater to the tip
- Height: 0.37 in.
