HONEYWELL
#31NT91-6F
Switch, Toggle; Bat-Handle; 10A/125V; SPST; On-Off
SKU
#
78454964949
Manufacturer Series:
31NT91 Series
Specifications
Type:
Bat-Handle Toggle Switch
Circuit Configuration:
SPST
Circuit Operation:
On-Off (momentary / maintained)
Amps/125V:
10A/125V
Amps/250V:
10A/250V
Horsepower:
0.25Hp/125Vac, 0.5Hp/250, 277Vac
Voltage:
277V AC
Terminal Type:
Quick-Connect
Terminal Size:
0.25 in Tab
Application Approval Listings:
Weatherproof
Toggle Length:
1.05 in
Mounting:
Bushing ODxL: 15/32 x 0.47 in.
Temperature Range:
-40° to +160°F (-40° to +71°C)
Description
Additional Info: Locked In Extreme Position (Opposite Keyway), Silver Cadmium Oxide Contacts
