HONEYWELL
#BZE6-2RQ62
Switch, Limit; Compact; Top Push Rod Lever Head; 15A; SPDT 1NO-1NC
SKU
#
78454921320
Manufacturer Series:
E6 Series
Specifications
Type:
Compact Limit Switch
Rating - NEMA:
NEMA 1
Head/Operator:
Top Push Rod Lever
Operator Configuration:
Adjustable
Head Action:
Spring Return, Low Force
Poles/Contacts:
SPDT 1NO 1NC
Current Rating - nominal:
15A
Operating Force:
0.31 lb (1.39N) OF
Pre-Travel - Travel To Operate:
0.718 in (18.24mm) PT
Differential-Travel - Travel To Reset:
0.229 in (5.82mm) DT
Over-Travel/Total-Travel:
0.838 in (21.2mm) OT
Operating Temperature - min:
-25 deg F (-32 deg C)
Operating Temperature - max:
160 deg F (71 deg C)
Body Construction:
Die Cast Zinc
Connection Type:
Threaded Entry
Connection Size:
1/2 in. NPT
Electrical Rating - VAC/DC:
15A 480Vac (Vdc Rated)
Description
Additional Info: Side Mount Switch. Adjustable 360deg Horiz. in 45deg increments, 250deg Vert.
