HONEYWELL
#BZ-2RW82276T
Switch, Limit; Basic; Roller Lever Head; SPDT 1NO-1NC; 15A
SKU
#
78454918188
Manufacturer Series:
BZ Series
Specifications
Type:
Basic Limit Switch
Head:
Roller Lever
Operator Configuration:
Standard
Head Action:
Spring Return, Standard
Poles/Contacts:
SPDT 1NO 1NC
Current Rating - nominal:
15A
Force to Operate:
6 oz (1.67N) OF
Differential-Travel - max:
0.015 in (0.38mm) DT
Over-Travel:
0.05 in (1.27mm) OT
Contact Rating:
15A 480V AC (VDC Rated)
Connection:
Solder Terminal
Connection Configuration:
14 AWG max
Operating Temperature:
-67°F (-55°C) to 185°F (85°C)
Construction:
Phenolic
Description
Additional Info: Silver Contact, Plastic Material
