SANYO DENKI
#9TP48P0H001
San Ace DC Tubeaxial Fan, 48 VDC, 76.8 w, 622 CFM, 221mm Dia
SKU
#
43975994156
Manufacturer Series:
C221 9T
Specifications
Type:
Bracket Mounted DC Tubeaxial Centrifugal Fan
Product Type:
Centrifugal Fan (Impeller)
Size:
221 x 71mm
Voltage:
48V DC
Voltage - Nominal:
48V DC
Power Input:
76.8 w
Air Flow:
622 CFM
Dimensions:
Dia: 221mm
Depth:
71mm
Noise Level - dB:
71 dBA
Bearing:
Ball
Termination Type:
(4) Wire Leads
Material - Housing:
Black Coated Aluminum
Material - Impeller:
Plastic
Temperature Max:
70°C
Temperature Min:
-20°C
Voltage Range:
36 to 72 VDC
Current Draw:
1.6 A
Motor:
3050 RPM, Locked Rotor Burnout Protection, Reverse Polarity Protection
