HEYCO PRODUCTS
#2077
Hole Bushing, Standard Nylon Push-In One-Piece 0.625 in
SKU
#
78311398983
Manufacturer Series:
Universal Bushing
Specifications
Type:
Hole Bushing, Standard
Mounting Hole Diameter:
0.625 in. (15.9mm)
Bushing Diameter:
0.437 in. (11.1mm)
Max. Panel Thickness:
0.125 in. (3.2mm)
Height - overall thickness:
0.406 in. (10.3mm)
Head Diameter:
0.730" (18.5 mm)
Installation:
Push-In One-Piece
Material:
Nylon
Color-Finish:
Black
Temperature Rating:
105 Degree C (221 Degree F) Max.
Material Specification:
Nylon Type 6/6 UL Rated 94V-2
Listing Description:
UB 625
