NVENT ERICO
#EHL12FC1K1K
Grounding Clamp, 6 to 4 AWG Sol, 1/2 in., Copper
SKU
#
78285651341
Specifications
Country of Origin:
United States - Subject to change
Connector Type:
Grounding Clamp
Application:
Cable to Rod
Connection Type:
Cable Parallel to Rod
Installation:
Hammerlock
Material:
Copper
Rod Size:
1/2 in.
AWG Min:
6 AWG Sol
AWG Max:
4 AWG Sol
Description
The nVent ERICO Hammerlock irreversible mechanical connection connects the grounding conductor to the ground rod. Machined from highly conductive copper, the state-of-the-art Hammerlock provides a low resistance connection designed to withstand ground fau
