SITOP Power Supply, DC; Switcher; 240VAC Input; 12VDC Output; 100w

Description

DC Power Supplies: Type - DC Power Supply; Design Mode - Switcher; Rating - Watts - 100W; Input VAC Nominal - 1PH 240VAC; Input VAC Range - 100-240VAC; Operating VAC Range - 85-264VAC; Output VDC Nominal - 12VDC; Output Current Nominal - 8.3A; Output VDC Range - 11.0-14.0VDC; Output Current Range - 0-8.3A; Input Current - 2.00A/1.10A; Efficiency - 84 Percent; Mounting - Wall Mount; Dimensions - HxWxD: 6.22x3.81x1.50 in. (158.0x97.0x38.0mm); Rating/Application - Class 1, IP20; Additional Information - Operating Temperature: -10 to 70 deg C (14 to 158 deg F); Manufacturer Series - SITOP PSU100D

Additional Info: Operating Temperature: -10 to 70 deg C (14 to 158 deg F)
