SIEMENS
#4AV32002EB000A
Power Supply; DC; 480W; 3PH 230/400VAC Nominal Input; 24VDC 20/24VDC 60 deg C, 24A/24VDC 40 deg C Nominal Output; 200-600VAC; 230-415VAC Operating; 15-180A Output; Screw Mount
SKU
#
04089292905
Manufacturer Series:
4AV
Specifications
Type:
Non-Stabilized DC Power Supply
Rating - Watts:
480W
Input VAC Nominal:
3PH 230/400VAC
Input VAC Range:
200-600VAC
Operating VAC Range:
230-415VAC
Output VDC Nominal:
24V DC
Output Current Nominal:
20/24VDC 60 deg C, 24A/24VDC 40 deg C
Output Current Range:
15-180A
Mounting:
Screw Mount
Rating/Application:
IP00
Description
Thanks to their rugged design, the 4AV devices feature a very high reliability. They are extremely resistant to the influence of external mains interferences and have a dampening effect on EMC. They are also suitable for the supply of capacitive loads as the connection of these consumers causes only minor voltage drops.
