LAMBDA #DPP30-12

Power Supply, DC; Switcher; 265VAC Input; 12VDC Output; 30w

SKU # 78988298966 Manufacturer Series: DPP
RoHS Compliant
Please enter a valid quantity
Unit of Sale: EA Order in multiples of: 1
Unable to add item(s) to cart. Please try again.
Type: DC Power Supply
Design Mode: Switcher
Rating - Watts: 30W
Input VAC Nominal: 1PH 265VAC
Input VAC Range: 85-264VAC
Operating VAC Range: 85-264VAC
Input VDC Range: 90-350VDC
Output VDC Nominal: 12V
Output Current Nominal: 2.5A/12VDC
Output VDC Range: 9.9-12.1VDC
Input Current: 0.72A
Efficiency: 83.0% typical
Mounting: DIN Rail Mount
Dimensions: HxWxD: 1.77 x 2.95 x 3.58 in. (44.9 x 74.9 x 90.9mm)
Rating/​Application: Class 1 Div. 2

Additional Info: Frequency: 47-63 Hz, Operating Temperature: -10 to 71 Deg C (14 to 159 Deg F)
