Actuator/Sensor Distribution Box, 10-30VDC, 5 Poles

SKU # 49100089793

Specifications

Base Type: Actuator/Sensor Distribution Box

Outlet Configuration: 5 Pole

Rating - Voltage: 10 to 30V DC

Rating - Current: 4A per Port/10A per Unit

Inlet Mating Size: M12x1

Outlet Mating Size: M23x1

Application/Rating - NEMA: NEMA 6P

Application/Rating - IEC: IP 67

Material: Thermoplastic Polyurethane

Dimensions: 5.98 in. H x 2.36 in. W x 1.18 in. D (152.0x60.0x30.3mm)

Temperature Rating: -15 to 80 deg C (5 to 176 deg F)
