EATON BUSSMANN SERIES
#TCF175RN
Finger Safe Cube Fuse, 175 A, 600 VAC, 300 VDC
SKU
#
05171269794
Manufacturer Series:
TCF_RN
Specifications
Country of Origin:
Multiple - Subject to change
Type:
Finger Safe Cube Fuse
Class:
CF
Characteristics:
Dual Element, Time Delay
Interrupting Rating:
200kA IR
Voltage:
600V AC / 300V DC
Amps:
175A
Dimensions:
LxWxH: 92 x 74 x 34mm
Holder:
TCFH175N
Connection:
Radial Blade Plug-in
Indicators:
Non-Indicating
Description
The Bussmann™ series Low-Peak™ CUBEFuse™ is a UL® Class CF current-limiting, dual-element, time-delay branch circuit fuse with Class J electrical performance. Available in indicating and non-indicating versions, this finger-safe fuse has a very compact, space-saving size and is easily applied using the CUBEFuse holder (TCFH_N), UL 98 Compact Circuit Protector switch (CCP2-_CF) or Compact Circuit Protector Base (CCP2B up to 100 A) used in the Quik-Spec™ coordination panelboard).
