EATON
#FAZ-C32/3
Supplementary Circuit Breaker, 3 Poles, 32A, 480VAC, 10 kA IR, 5-10 x Rating Trip, Screw Terminals
SKU
#
40150878876
Specifications
Type:
Supplementary Thermal Circuit Breaker
Poles:
3P
Amps:
32A
Trip Range:
5-10X of Rated Current for Instantaneous
Voltage:
480Y/277V AC; 96V DC
Rating - kA IR:
10
Actuator Style:
Toggle Lever
Mounting:
DIN Rail
Terminals:
Screw
WxHxD:
2.09 x 4.13 x 2.36 in. (51.1 x 105.0 x 60.0mm)
Description
Optimum product quality, tested reliability and safety stand for best protection of personnel, installations and plant. Eaton's FAZ-NA DIN rail mountable circuit breaker is designed for use in branch service applications. UL 1077; Standard Packaging
