PHOENIX CONTACT
#1819134
PCB Terminal Block, 7 Positions, 800 V, 41 A, 7.5mm Pitch
SKU
#
78037341395
Specifications
Type:
PCB Terminal Block
Block Configuration:
1 Level
Number of Positions:
7
Pitch - spacing:
7.5mm
Voltage - Nominal:
800 V
Current - nominal:
41 A
Wire Size:
24 to 8 AWG
Wire Connection Type:
Push-in Spring
Wire Connection Angle:
30°
Block Connection Type:
1.7 x 0.8mm Pin
Block Width:
54.3mm
Block Height:
38.6mm
Block Depth:
29mm
Temperature Rating:
-40° to +100°C
Material:
Polyamide
Color:
RAL 6021 Pale Green
Package Quantity:
50
