PHOENIX CONTACT
#1990876
PCB Terminal Block, 4 Positions, 160 V, 17.5 A, 3.5mm Pitch
SKU
#
78037394777
Specifications
Type:
PCB Terminal Block
Block Configuration:
1 Level
Number of Positions:
4
Pitch - spacing:
3.5mm
Voltage - Nominal:
160V
Current - nominal:
17.5 A
Wire Size:
24 to 16 AWG
Wire Connection Type:
Push-in Spring
Wire Connection Angle:
90°
Block Connection Type:
0.8 x 0.8mm Pin
Block Width:
15.4mm
Block Height:
16.9mm
Block Depth:
13.5mm
Temperature Rating:
-40° to +105°C
Material:
Polyamide
Color:
RAL 6021 Pale Green
Package Quantity:
100
